RATED OUTPUT POWER ............................................... 1000 watts
INPUT FOR RATED OUTPUT .......................................... 1.0 milliwatt maximum
POWER OUTPUT @ 1 dB COMPRESSION ..................... 900 watts nominal
700 watts minimum
FREQUENCY RESPONSE ............................................... 10 kHz–225 MHz instantaneously
GAIN (at maximum setting) ........................................... 60 dB minimum
FLATNESS ..................................................................... ± 3.0 dB maximum
± 1.0 dB with internal leveling
GAIN ADJUSTMENT (continuous range) ......................... 20 dB minimum
INPUT IMPEDANCE ....................................................... 50 ohms, VSWR 1.5:1 maximum
OUTPUT IMPEDANCE ................................................... 50 ohms nominal
MISMATCH TOLERANCE ............................................... 100% rated power without foldback up to 6.0:1 mismatch abovewhich may
limit to 500 watts reflected power.
MODULATION CAPABILITY ........................................... Will faithfully reproduce AM, FM or Pulse modulation appearing on the input
signal.
HARMONIC DISTORTION............................................. Minus 20 dBc maximum at 750 watts
THIRD ORDER INTERCEPT POINT .................................. 68 dBm typical
RF POWER DISPLAY ...................................................... 0–2000 watts full scale
RF RISE/FALL TIME ........................................................ 10 nanoseconds maximum
PRIMARY POWER .......................................................... 187–264 VAC
47–63 Hz, single phase
5,000 watts maximum at .95 P.F. typical
