RATED OUTPUT POWER ............................................... 10,000 watts minimum, 10 kHz–100 MHz
10,000–6000 watts minimum, 100 MHz–225 MHz
(derating slope of 32 watts/MHz)
INPUT FOR RATED OUTPUT .......................................... 1.0 milliwatt maximum
POWER OUTPUT @ 1 dB COMPRESSION ..................... 7000 watts, 10 kHz–100 MHz
7000–4000 watts, 100 MHz–225 MHz
(derating slope of 24 watts/MHz)
FREQUENCY RESPONSE ............................................... 10 kHz–225 MHz instantaneously
GAIN (at maximum setting) ........................................... 70 dB minimum
FLATNESS ..................................................................... ± 3.0 dB maximum
± 1.0 dB with internal leveling
GAIN ADJUSTMENT (continuous range) ......................... 20 dB minimum
INPUT IMPEDANCE ....................................................... 50 ohms, VSWR 1.5:1 maximum
OUTPUT IMPEDANCE ................................................... 50 ohms, nominal
