Frequency range 100kHz…1GHz/3GHz
 Amplitude measurement range -114dBm…+20dBm
DANL -135dBm with Preamp. Option HO3011
Sweep time 20ms...1000s
Resolution bandwidth 100Hz…1MHz in 1-3 Steps, 200kHz (-3dB)
additional 200Hz (HMS3000/3010), 9kHz, 120kHz, 1MHz (-6dB)
Spectral purity ‹ -100dBc/Hz (@100kHz)
Video bandwidth 10Hz...1MHz in 1-3 steps
Tracking Generator (HMS1010/3010) -20dBm…0dBm
in 1dB steps
 Integrated AM and FM demodulator (headset output)
 Detectors: Auto-, min-, max-peak, sample, RMS, quasi-peak
 8 Marker with delta marker, miscellaneous peak functions
 6.5” TFT color VGA display, DVI output
 3 x USB for mass-storage, printer and remote control
optional IEEE-488 (GPIB) or Ethernet/USB Interface
